Cleaning and replacing filte
rs
Engine oil filter
1
- Engine Oil Filter
Using the oil filter wrench, scre
w the filter anticlockwise to
remove it. Lightly lubricate the rubber seal ring on
the new
filter with oil, rotate clockw
ise until the seal re
aches the
sealing surface, a
nd then rotate another 2/3
turn to tighten
it properly.
U18N080
MAINTENANCE INSTRUCTIONS
101
101
