Some of the universal symbols have been shown below with an indication of their meaning.
Engine
speed rev/minX100
Pressured-open slowly Corrosive substance
Hours, recorded Continuous variable
''Tortoise'' Slow or
minimum setting
Engine coolant
temperature
Warning
''Hare'' fast or maximum
setting
Fuel level Hazard warning
Transmission oil
pressure
Engine stop control Neutral Turn signal
Lights Fan
Transmission oil
temperature
Horn Power take off engaged Parking brake
Engine oil pressure
Power take off
disengaged
Work lamps
Air filter Lift arm/raise Differential lock
Battery charge Lift arm/lower See operator's manual
