Installation example in Rittal VX25
enclosure
Contents of this chapter
In this chapter, the drive module is installed in a 800 mm wide Rittal VX25 enclosure in a
bookshelf way of mounting. The module is placed in an upright position on the cabinet
bottom with its front facing the cabinet door. Available alternative ABB parts are also given.
For control cable installation, see chapter Electrical installation (page 95).
Limitation of liability
The installation must always be designed and made according to applicable local laws and
regulations. ABB does not assume any liability whatsoever for any installation which breaches
the local laws and/or other regulations. Furthermore, if the recommendations given by ABB
are not followed, the drive may experience problems that the warranty does not cover.
Safety
WARNING!
Obey the safety instructions of the drive. If you ignore them, injury or death,
or damage to the equipment can occur.
11
Installation example in Rittal VX25 enclosure 133
