Start-up (page 143)

Commission the drive.

Appropriate firmware manual

Operate the drive: start, stop, speed control etc.

Terms and abbreviations

DescriptionTerm

Type of control unitCCU-24

115/230 V digital input extension moduleCHDI-01

Multifunction extension module (external 24 V AC/DC and digital I/O extension)CMOD-01

Multifunction extension module (external 24 V AC/DC and isolated PTC interface)CMOD-02

Frequency converter for controlling AC motorsDrive

Electromagnetic compatibilityEMC

Electromagnetic interferenceEMI

BACnet/IP adapter moduleFBIP-21

Optional CANopen® adapter moduleFCAN

Optional ControlNet™ adapter moduleFCNA-01

Optional DeviceNet™ adapter moduleFDNA-01

Optional EtherCAT adapter moduleFECA

Optional Ethernet adapter module for EtherNet/IP™, Modbus TCP and PROFINET

IO protocols

FENA-01

Optional Ethernet POWERLINK adapter moduleFEPL-02

Optional Ethernet adapter module for Modbus TCP protocolFMBT-21

Optional PROFIBUS DP® adapter moduleFPBA-01

Optional Profinet IO adapter moduleFPNO-21

Physical size of the drive or power moduleFrame, frame size

Optional RS-485 (Modbus/RTU) adapterFSCA-01

Insulated gate bipolar transistorIGBT

Inverter module(s) under control of one control unit, and related components. One

inverter unit typically controls one motor.

Inverter unit

Remote monitoring toolNETA-21

Programmable logic controllerPLC

Common term for drive module, inverter module, supply module, brake chopper

module etc.

Power module

Radio-frequency interferenceRFI

Safe torque off (IEC/EN 61800-5-2)STO

Supply module(s) under control of one control unit, and related components.Supply unit
