Page #196 background image
Drive1
Control unit2
Control logic3
To motor4
Activation switchK
Wiring examples
Single ACQ580-34 drive, internal power supply
2414
2313 Y1
A2
Y2
A1
31
32
OUT
GND
OUT134
OUT235
SGND36
IN137
IN238
STO
1
K
2
Drive1
Safety PLC2
Safety relayK
Single ACQ580-34 drive, external power supply
2414
2313 Y1
A2
Y2
A1
31
32
OUT
GND
K
- +
2
24 V DC
1
OUT134
OUT235
SGND36
IN137
IN238
STO
Drive1
Safety PLC2
Safety relayK
196 The Safe torque off function
