ABB ACS180 User Manual

128 Parameters
11.03 DIO force selection Selects the digit outputs that will be controlled by
parameter 11.04. The signals connected to the digit
outputs can be overridden for eg. testing purposes. A bit
in parameter 11.04 DO1 force data is provided for each
digit output, and its value is applied whenever the
corresponding bit in this parameter is 1.
Note: Boot and power cycle reset the force selections
(parameters 11.03 and 11.04).
0000h
0000h...FFFFh Forced selections of digital inputs/outputs. 1=1
11.04 DO1 force data Contains the values of digit outputs that are used instead
of the connected signals if selected in parameter 11.03
DIO force selection. Bit 0 is the forced value for DO1.
This provides the possibility to test the drive functionality
without the plant wiring. T
on
and T
off
delays are passed.
0000h
0000h...FFFFh Forced values of digital outputs. 1=1
11.06 DO1 output source Selects a drive signal to be connected to digital output
DO1.
Not
energized
Not energized Output is not energized. 0
Energized Output is energized. 1
Ready run Bit 1 of 06.11 Main status word. 2
Enabled Bit 0 of 06.16 Drive status word 1.4
Started Bit 5 of 06.16 Drive status word 1.5
Magnetized Bit 1 of 06.17 Drive status word 2.6
Running Bit 6 of 06.16 Drive status word 1.7
Ready ref Bit 2 of 06.11 Main status word.8
At setpoint Bit 8 of 06.11 Main status word.9
Reverse Bit 2 of 06.19 Speed control status word.10
Zero speed Bit 0 of 06.19 Speed control status word.11
Above limit Bit 10 of 06.17 Drive status word 2.12
Warning Bit 7 of 06.11 Main status word.13
Fault Bit 3 of 06.11 Main status word.14
Fault (-1) Inverted bit 3 of 06.11 Main status word.15
Fault/Warning A warning or fault is active. 16
Overcurrent A drive is tripped to overcurrent fault. 17
No. Name/Value Description Default
FbEq 16
Bit Value
0 1 = Force DO1 to value of bit 0 of parameter 11.04 DO1 force data.
1...15 Reserved
Bit Value
0 1 = Force the value of this bit to DO1, if so defined in parameter 11.03 DO force
selection.
1...15 Reserved
ACS180 FW.book Page 128 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
