ABB ACS180 User Manual

Parameters 169
Enabled (init at stop/
power-up)
When enabled, the motor potentiometer first adopts the
value defined by parameter 22.72. The value can then be
adjusted from the up and down sources defined by
parameters 22.73 and 22.74.
A power cycle will reset the motor potentiometer to the
predefined initial value (22.72).
1
Enabled (resume
always)
As Enabled (init at stop/ power-up), but the motor
potentiometer value is retained over a power cycle.
2
Enabled (init to actual) Whenever another reference source is selected, the value
of the motor potentiometer follows that reference. After
the source of reference returns to the motor
potentiometer, its value can again be changed by the up
and down sources (defined by 22.73 and 22.74).
3
Enabled (resume/init
to Actual)
As Enabled (init to actual), but the motor potentiometer ref
act value is retained over power cycle.
4
22.72 Motor potentiometer
initial value
Defines an initial value (starting point) for the motor
potentiometer. See the selections of parameter 22.71.
0.00
-32768.00… 32767.00 Initial value for motor potentiometer. 1 = 1
22.73 Motor potentiometer
up source
Selects the source of motor potentiometer up signal.
0 = No change
1 = Increase motor potentiometer value. (If both the up
and down sources are on, the potentiometer value will not
change.)
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
Supervision 1 Bit 0 of 32.01 Supervision status.24
Supervision 2 Bit 1 of 32.01 Supervision status.25
Supervision 3 Bit 2 of 32.01 Supervision status.26
Supervision 4 Bit 3 of 32.01 Supervision status.27
Supervision 5 Bit 4 of 32.01 Supervision status.28
Supervision 6 Bit 5 of 32.01 Supervision status.29
Other [bit] Source selection (see
Terms and abbreviations). -
22.74 Motor potentiometer
down source
Selects the source of motor potentiometer down signal.
0 = No change
1 = Decrease motor potentiometer value. (If both the up
and down sources are on, the potentiometer value will not
change.)
For the selections, see parameter 22.73.
Not selected
No. Name/Value Description Default
FbEq 16
ACS180 FW.book Page 169 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
