226 Parameters
35.53 Break point Defines the motor load curve together with parameters
35.51 Motor load curve and 35.52 Zero speed load.
Defines the break point frequency of the load curve ie. the
point at which the motor load curve begins to decrease
from the value of parameter 35.51 Motor load curve
towards the value of parameter 35.52 Zero speed load.
See parameter 35.51 Motor load curve.
45.00 Hz
1.00…500.00 Hz Break point for the motor load curve. See par.
46.02
35.54 Motor nominal
temperature rise
Defines the temperature rise of the motor above ambient
when the motor is loaded with nominal current. See the
motor manufacturer's recommendations.
The unit is selected by parameter 96.16 Unit selection.
80 °C or
176 °F
0…300 °C or
32…572 °F
Temperature rise. 1 = 1°
No. Name/Value Description Default
FbEq 16
Motor nominal
temperature rise
Temperature
Time
Ambient temperature
