ABB ACS180 User Manual

236 Parameters
40.06 Process PID status
word
Displays status information on process PID control.
This parameter is read-only.
0000h
0000h…FFFFh Process PID control status word. 1 = 1
40.07 Process PID operation
mode
Activates/deactivates process PID control.
Note: Process PID control is only available in external
control; see section Local and external control locations
(page 44).
Off
Off Process PID control inactive. 0
On Process PID control active. 1
On when drive running Process PID control is active when the drive is running. 2
40.08 Set 1 feedback 1
source
Selects the primary source of process feedback. See the
control chain diagram on page 386.
Not selected
Not selected None. 0
AI1 scaled 12.12 AI1 scaled value 1
AI2 scaled 12.22 AI2 scaled value 2
Freq in scaled 11.39 Freq in 1 scaled value 3
AI1 percent 12.101 AI1 percent value 8
AI2 percent 12.102 AI2 percent value 9
Feedback storage 40.91 Feedback data storage 10
Other Source selection (see Terms and abbreviations). -
40.09 Set 1 feedback 2
source
Selects the second source of process feedback. The
second source is used only if the setpoint function
requires two inputs.
For the selections, see parameter 40.08 Set 1 feedback 1
source.
Not selected
40.10 Set 1 feedback
function
Defines how process feedback is calculated from the two
feedback sources selected by parameters 40.08 Set 1
feedback 1 source and 40.09 Set 1 feedback 2 source.
In1
In1 Source 1. 0
No. Name/Value Description Default
FbEq 16
Bit Name Value
0 PID active 1 = Process PID control active.
1 Setpoint frozen 1 = Process PID setpoint frozen.
2 Output frozen 1 = Process PID controller output frozen.
3 PID sleep mode 1 = Sleep mode active.
4 Sleep boost 1 = Sleep boost active.
5 Trim mode 1 = Trim function active.
6 Tracking mode 1 = Tracking function active.
7 Output limit high 1 = PID output is being limited by parameter 40.37.
8 Output limit low 1 = PID output is being limited by parameters 40.36
9 Deadband active 1 = Deadband active (see parameter 40.39)
10 PID set 0 = Parameter set 1 in use. 1 = Parameter set 2 in use.
11 Reserved
12 Internal setpoint
active
1 = Internal setpoint active (see parameters 40.16…40.23)
13…15 Reserved
ACS180 FW.book Page 236 Tuesday, March 9, 2021 2:25 PM

ABB ACS180 Specifications

General

Product Type	DC Drive
Number of Phases	1 or 3
IP Rating	IP20
Communication Interfaces	Modbus RTU
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-40 to +70 °C
Relative Humidity	5 to 95 % non-condensing
Altitude	Up to 1000 m
