ABB ACS180 User Manual

250 Parameters
41.17 Set 2 setpoint 2
source
See parameter 40.17 Set 1 setpoint 2 source. Not selected
41.18 Set 2 setpoint function See parameter 40.18 Set 1 setpoint function. In1
41.19 Set 2 internal setpoint
sel1
See parameter 40.19 Set 1 internal setpoint sel1. Not selected
41.20 Set 2 internal setpoint
sel2
See parameter 40.20 Set 1 internal setpoint sel2. Not selected
41.21 Set 2 internal setpoint
1
See parameter 40.21 Set 1 internal setpoint 1. 0.00 PID
customer
units
41.22 Set 2 internal setpoint
2
See parameter 40.22 Set 1 internal setpoint 2. 0.00 PID
customer
units
41.23 Set 2 internal setpoint
3
See parameter 40.23 Set 1 internal setpoint 3. 0.00 PID
customer
units
41.24 Set 2 internal setpoint
0
40.24 Set 1 internal setpoint 0. 0.00 PID
customer
units
41.26 Set 2 setpoint min See parameter 40.26 Set 1 setpoint min.0.00
41.27 Set 2 setpoint max See parameter 40.27 Set 1 setpoint max. 200000.00
41.28 Set 2 setpoint increase
time
See parameter 40.28 Set 1 setpoint increase time. 0.0 s
41.29 Set 2 setpoint
decrease time
See parameter 40.29 Set 1 setpoint decrease time. 0.0 s
41.30 Set 2 setpoint freeze
enable
See parameter 40.30 Set 1 setpoint freeze enable. Not selected
41.31 Set 2 deviation
inversion
See parameter 40.31 Set 1 deviation inversion. Not inverted
(Ref - Fbk)
41.32 Set 2 gain See parameter 40.32 Set 1 gain.1.00
41.33 Set 2 integration time See parameter 40.33 Set 1 integration time.60.0 s
41.34 Set 2 derivation time See parameter 40.34 Set 1 derivation time. 0.000 s
41.35 Set 2 derivation filter
time
See parameter 40.35 Set 1 derivation filter time. 0.0 s
41.36 Set 2 output min See parameter 40.36 Set 1 output min.0.00
41.37 Set 2 output max See parameter 40.37 Set 1 output max.100.00
41.38 Set 2 output freeze
enable
See parameter 40.38 Set 1 output freeze enable. Not selected
41.39 Set 2 deadband range See parameter 40.39 Set 1 deadband range.0.0
41.40 Set 2 deadband delay See parameter 40.40 Set 1 deadband delay. 0.0 s
41.43 Set 2 sleep level See parameter 40.43 Set 1 sleep level.0.0
41.44 Set 2 sleep delay See parameter 40.44 Set 1 sleep delay.60.0 s
41.45 Set 2 sleep boost time See parameter 40.45 Set 1 sleep boost time. 0.0 s
41.46 Set 2 sleep boost step See parameter 40.46 Set 1 sleep boost step. 0.0 PID
customer
units
No. Name/Value Description Default
FbEq 16
