ABB ACS380 Series User Manual

126 Parameters
-32768 … 32767 1 = 1
11.59 Freq out 1 src max Defines the minimum value for frequency output 1. 1500
-32768 … 32767 1 = 1
11.60 Freq out 1 at src min Defines the real value that corresponds to the minimum
frequency output 1 value defined by parameter Freq out 1
min.
0 Hz
0 … 16000 Hz 1 = 1 Hz
11.61 Freq out 1 at src max Defines the real value that corresponds to the maximum
frequency output 1 value defined by parameter Freq out 1
max.
16000 Hz
0 … 16000 Hz 1 = 1 Hz
11.62 Freq out 2 actual value Unscaled and undelayed Frequency output 2 value. -
0 … 16000 Hz 1 = 1 Hz
11.63 Freq out 2 source Selects a drive signal to be connected to the frequency
output 2.
For the available selections, see parameter 11.55 Freq out
1 source.
Not selected
11.66 Freq out 2 source min Defines the minimum value for frequency output 2. 0
-32768 … 32767 1 = 1
11.67 Freq out 2 source max Defines the minimum value for frequency output 2. 1500
-32768 … 32767 1 = 1
11.68 Freq out 2 at src min Defines the real value that corresponds to the minimum
frequency output 2 value defined by parameter Freq out 2
min.
0 Hz
0 … 16000 Hz 1 = 1 Hz
11.69 Freq out 2 at src max Defines the real value that corresponds to the maximum
frequency output 2 value defined by parameter Freq out 2
max.
16000 Hz
0 … 16000 Hz 1 = 1 Hz
12
12 Standard AI
Configuration of standard analog inputs.
12.02 AI force selection The true readings of the analog inputs can be overridden
for e.g. testing purposes. A forced value parameter is
provided for each analog input, and its value is applied
whenever the corresponding bit in this parameter is 1.
Note: AI filter times (parameters 12.16 AI1 filter time and
12.26 AI1 filter time) have no effect on forced AI values
(parameters 12.13 AI1 forced value and 12.23 AI2 forced
value).
Note: Boot and power cycle reset the force selections
(parameter 12.02).
0000h
0000h…FFFFh Forced values selector for analog inputs AI1 and AI2. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Value
0 1 = Force AI1 to value of parameter 12.13 AI1 forced value.
1 1 = Force AI2 to value of parameter 12.23 AI2 forced value.
2…15 Reserved
