118 Parameters
10
10 Standard DI, RO
Configuration of digital inputs and relay outputs.
10.02 DI delayed status Displays the status of digital inputs. This word is updated
only after activation / deactivation delays.
0000h
0000h…FFFFh Delayed status of digital inputs. 1 = 1
10.03 DI force selection Selects the digital inputs, states of which will be controlled
by parameter 10.04 DI forced data. A bit in parameter
10.04 DI forced data is provided for each digital input, and
its value is applied whenever the corresponding bit in this
parameter is 1.
Note: Boot and power cycle reset the force selections
(parameters 10.03 and 10.04).
0000h
0000h…FFFFh Override selection for digital inputs. 1 = 1
10.04 DI forced data Defines the forced values for the digital inputs selected by
parameter 10.03 DI force selection. It is only possible to
force an input that has been selected in parameter 10.03
DI force selection.
Bit 0 is the forced value for DI1.
0000h
0000h…FFFFh Forced values of digital inputs. 1 = 1
bit 0 DI1 Set state of DI1.
bit 1 DI2 Set state of DI2.
bit 2 DI3 Set state of DI3.
bit 3 DI4 Set state of DI4.
bit 4...15 Reserved
10.21 RO status Status of relay outputs RO3…RO1. Example: 00000001b
= RO1 is energized, RO2…RO3 are de-energized.
-
0000h…FFFFh Status of relay outputs. 1 = 1
bit 0 RO1 Status of relay output 1.
b1...5 Reserved
No. Name/Value Description Default
FbEq 16
Bit Value
0 DI1 = Delayed status of digital input 1.
1 DI2 = Delayed status of digital input 2.
2 DI3 = Delayed status of digital input 3.
3 DI4 = Delayed status of digital input 4.
4...15 Reserved.
Bit Value
0 1 = Force DI1 to value of bit 0 of parameter 10.04 DI forced data.
1 1 = Force DI2 to value of bit 1 of parameter 10.04 DI forced data.
2 1 = Force DI3 to value of bit 2 of parameter 10.04 DI forced data.
3 1 = Force DI4 to value of bit 3 of parameter 10.04 DI forced data.
4...15 Reserved.
