Parameters 119
10.22 RO force selection Selects the relay outputs that will be controlled by
parameter 10.23. The signals connected to the relay
outputs can be overridden for eg. testing purposes. A bit in
parameter 10.23 RO forced data is provided for each relay
output, and its value is applied whenever the
corresponding bit in this parameter is 1.
Note: Boot and power cycle reset the force selections
(parameters 10.22 and 10.23).
0000h
0000h…FFFFh Override selection for relay outputs. 1 = 1
10.23 RO forced data Sets the override value 0=off or 1=on per each relay
output.
This is effective only if corresponding RO is selected from
parameter 10.22. This provides the possibility to test the
drive functionality without the plant wiring. Ton and Toff
delays are passed.
0000h…FFFFh Forced RO values. 1 = 1
10.24 RO1 source Selects a drive signal to be connected to relay output
RO1.
Ready run
Not energized Output is not energized. 0
Energized Output is energized. 1
Ready run Bit 1 of 06.11 Main status word. 2
Enabled Bit 0 of 06.16 Drive status word 1.4
Started Bit 5 of 06.16 Drive status word 1.5
Magnetized Bit 1 of 06.17 Drive status word 2.6
Running Bit 6 of 06.16 Drive status word 1.7
Ready ref Bit 2 of 06.11 Main status word.8
At setpoint Bit 8 of 06.11 Main status word.9
Reverse Bit 2 of 06.19 Speed control status word.10
Zero speed Bit 0 of 06.19 Speed control status word.11
Above limit Bit 10 of 06.17 Drive status word 2.12
Warning Bit 7 of 06.11 Main status word.13
Fault Bit 3 of 06.11 Main status word.14
Fault (-1) Inverted bit 3 of 06.11 Main status word.15
Fault/Warning A warning or fault is active. 16
Overcurrent A drive is tripped to overcurrent fault. 17
Overvoltage A drive is tripped to overvoltage fault. 18
Drive temp A drive is tripped to drive temperature fault. 19
Undervoltage A drive is tripped to undervoltage fault. 20
Motor temp A drive is tripped to motor temperature fault. 21
Brake command Bit 0 of 44.01
Brake control status. 22
No. Name/Value Description Default
FbEq 16
Bit Value
0 1 = Force RO1 to value of bit 0 of parameter 10.23 RO forced data.
1…15 Reserved
