Parameters 135
13.20 AO1 out at AO1 src
max
Defines the maximum output value for analog output AO1.
See also drawing at parameter 13.17 AO1 source min.
20.000 mA
0.000…22.000 mA Maximum AO1 output value. 1000 = 1 mA
13.91 AO1 data storage Storage parameter for controlling analog output AO1 eg.
through the embedded fieldbus interface.
In parameter 13.12 AO1 source, select AO1 data storage.
Then set this parameter as the target of the incoming
value data. With the embedded fieldbus interface, set the
target selection parameter of that particular data
(58.101…58.114 to AO1 data storage).
0.00
-327.68 … 327.67 Storage parameter for AO1. 100 = 1
15
15 I/O extension module
Configuration of the I/O extension module.
Note: The contents of the parameter group vary according
to the selected I/O extension module type.
15.01 Extension module type Activates (and specifies the type of) I/O extension module.
If the value is None, when an extension module has been
installed and the dive is powered, the drive automatically
sets the value to the type it has detected (= value of
parameter 15.02 Detected extension module); otherwise
warning A7AB Extension I/O configuration failure is
generated and you have to set the value of this parameter
manually.
None
None Inactive. 0
BREL External relay option BREL-01. 5
15.02 Detected extension
module
Shows the I/O extension module the control program has
automatically detected on the drive.
None
None Inactive. 0
BREL External relay option BREL-01. 5
15.04 RO/DO status Displays the status of the relay outputs RO2, RO3, RO4
and RO5 on the extension module.
-
0000h…FFFFh Status of relay/digital outputs. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Value
0 Status of RO2 (1= relay closed, 0=relay open)
1 Status of RO3 (1= relay closed, 0=relay open)
2 Status of RO4 (1= relay closed, 0=relay open)
3 Status of RO5 (1= relay closed, 0=relay open)
4...15 Reserved
