ABB ACS380 Series User Manual

Parameters 229
36.50 AL2 reset date The date on which amplitude logger 2 was last reset. 01.01.1980
- Last reset date of amplitude logger 2. -
36.51 AL2 reset time The time at which amplitude logger 2 was last reset. 00:00:00
- Last reset time of amplitude logger 2. -
37
37 User load curve
Settings for user load curve.
See also section User load curve (page 69).
37.01 ULC output status
word
Displays the status of the monitored signal (37.02). 0000h
0000h…FFFFh Status of the monitored signal. 1 = 1
37.02 ULC supervision
signal
Selects the signal to be supervised. Motor
torque %
Not selected No signal selected. ULC disabled. 0
Motor speed % 01.03 Motor speed %.1
Motor current % 01.08 Motor current % of motor nom.2
Motor torque % 01.10 Motor torque.3
Output power % of
motor nom
01.15 Output power % of motor nom.4
Output power % of
drive nom
01.16 Output power % of drive nom. 5
Other Source selection (see Terms and abbreviations). -
37.03 ULC overload actions Selects an action taken if the signal (37.02) stays over the
overload curve for a defined time.
Disabled
Disabled No warnings or fault generated. 0
Warning The drive generates an A8C1 ULC overload warning if the
signal has been continuously over the overload curve for a
time defined by parameter 37.41 ULC overload timer.
1
Fault The drive generates an 8002 ULC overload fault if the
signal has been continuously over the overload curve for a
time defined by parameter 37.41 ULC overload timer.
2
Warning/Fault The drive generates an A8C1 ULC overload warning if the
signal has been continuously over the overload curve for
half of the time defined by parameter 37.41 ULC overload
timer.
The drive generates an 8002 ULC overload fault if the
signal has been continuously over the overload curve for a
time defined by parameter 37.41 ULC overload timer.
3
37.04 ULC underload
actions
Selects an action taken if the signal (37.02) stays under
the underload curve for a defined time.
Disabled
Disabled No warnings or fault generated. 0
No. Name/Value Description Default
FbEq 16
Bit Name Description
0 Under load limit 1 = Signal lower than the underload curve.
1 Within load range 1 = Signal between the underload and overload curve.
2 Overload limit 1 = Signal higher than the overload curve.
3…15 Reserved
