ABB ACS380 Series User Manual

Parameters 305
98.07 Lq user Defines the quadrature axis (synchronous) inductance.
Note: This parameter is valid only for permanent magnet
motors.
0.00000 p.u.
0.00000 … 10.00000
p.u
Quadrature axis inductance in per unit. -
98.08 PM flux user Defines the permanent magnet flux.
Note: This parameter is valid only for permanent magnet
motors.
0.00000 p.u.
0.00000 … 2.00000
p.u
Permanent magnet flux in per unit. -
98.09 Rs user SI Defines the stator resistance R
S
of the motor model. 0.00000 ohm
0.00000…
100.00000 ohm
Stator resistance. -
98.10 Rs user SI Defines the rotor resistance R
R
of the motor model.
Note: This parameter is valid only for asynchronous
motors.
0.00000 ohm
0.00000…
100.00000 ohm
Rotor resistance. -
98.11 Lm user SI Defines the main inductance L
M
of the motor model.
Note: This parameter is valid only for asynchronous
motors.
0.00 mH
0.00…100000.00 mH Main inductance. 1 = 10000
mH
98.12 SigmaL user SI Defines the leakage inductance
σL
S
.
Note: This parameter is valid only for asynchronous
motors.
0.00 mH
0.00…100000.00 mH Leakage inductance. 1 = 10000
mH
98.13 Ld user SI Defines the direct axis (synchronous) inductance.
Note: This parameter is valid only for permanent magnet
motors.
0.00 mH
0.00 …100000.00 mH Direct axis inductance. 1 = 10000
mH
98.14 Lq user SI Defines the quadrature axis (synchronous) inductance.
Note: This parameter is valid only for permanent magnet
motors.
0.00 mH
0.00 …100000.00 mH Quadrature axis inductance. 1 = 10000
mH
99
99 Motor data
Motor configuration settings.
99.03 Motor type Selects the motor type.
Note: This parameter cannot be changed while the drive
is running.
Asynchro-
nous motor
Asynchronous motor Standard squirrel cage AC induction motor (asynchronous
induction motor).
0
No. Name/Value Description Default
FbEq 16
