214 Parameters
34.10 Timed functions
enable
Selects the source for the timed functions enable signal.
0 = Disabled.
1 = Enabled.
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1) 11
Other [bit] Source selection (see Terms and abbreviations). -
34.11 Timer 1 configuration Defines when timer 1 is active. 0000011110
000000
0000h…FFFFh Configuration of timer 1. 1 = 1
34.12 Timer 1 start time Defines the daily start time of timer 1. The time can be
changed in second steps.
The timer can be started at an other time than the start
time. E.g. if the timer's duration is more than one day and
the active session starts during the time, the timer is
started at 00:00 and stopped when there is no duration
left.
00:00:00
00:00:00…23:59:59 Daily start time of the timer. 1 = 1
No. Name/Value Description Default
FbEq 16
Bit Name Description
0 Monday 1 = Monday is an active start day.
1 Tuesday 1 = Tuesday is an active start day.
2 Wednesday 1 = Wednesday is an active start day.
3 Thursday 1 = Thursday is an active start day.
4 Friday 1 = Friday is an active start day.
5 Saturday 1 = Saturday is an active start day.
6 Sunday 1 = Sunday is an active start day.
7 Season 1 1 = Timer is active in season 1.
8 Season 2 1 = Timer is active in season 2.
9 Season 3 1 = Timer is active in season 3.
10 Season 4 1 = Timer is active in season 4.
11 Exceptions 0 = Exceptions days are disabled.
1 = Exception days are enabled. Bits 12 and 13 are taken
into account.
12 Holidays 0 = Timer is inactive on exception days configured as
"Holiday".
1 = Timer is active on exception days configured as
"Holiday".
13 Workdays 0 = Timer is inactive on exception days configured as
"Workday".
1 = Timer is active on exception days configured as
"Workday".
14…15 Reserved
