Additional parameter data 323
22.73 Motor potentiometer up
source
Binary src --1 = 1
22.74 Motor potentiometer down
source
Binary src --1 = 1
22.75 Motor potentiometer ramp
time
Real 0.0…3600.0 s 10 = 1 s
22.76 Motor potentiometer min
value
Real -32768.00…32767.00 - 100 = 1
22.77 Motor potentiometer max
value
Real -32768.00…32767.00 - 100 = 1
22.80 Motor potentiometer ref act Real -32768.00…32767.00 - 100 = 1
22.86 Speed reference act 6 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.87 Speed reference act 7 Real -30000.00…30000.00 rpm 100 = 1 rpm
23 Speed reference ramp
23.01 Speed ref ramp input Real -30000.00…30000.00 rpm 100 = 1 rpm
23.02 Speed ref ramp output Real -30000.00…30000.00 rpm 100 = 1 rpm
23.11 Ramp set selection Binary src --1 = 1
23.12 Acceleration time 1 Real 0.000 …1800.000 s 1000 = 1 s
23.13 Deceleration time 1 Real 0.000 …1800.000 s 1000 = 1 s
23.14 Acceleration time 2 Real 0.000 …1800.000 s 1000 = 1 s
23.15 Deceleration time 2 Real 0.000 …1800.000 s 1000 = 1 s
23.20 Acc time jogging Real 0.000 …1800.000 s 1000 = 1 s
23.21 Dec time jogging Real 0.000 …1800.000 s 1000 = 1 s
23.23 Emergency stop time Real 0.000 …1800.000 s 1000 = 1 s
23.28 Variable slope enable List 0…1 - 1 = 1
23.29 Variable slope rate Real 2…30000 ms 1 = 1 ms
23.32 Shape time 1 Real 0.000 …1800.000 s 1000 = 1 s
23.33 Shape time 2 Real 0.000 …1800.000 s 1000 = 1 s
24 Speed reference conditioning
24.01 Used speed reference Real -30000.00…30000.00 rpm 100 = 1 rpm
24.02 Used speed feedback Real -30000.00…30000.00 rpm 100 = 1 rpm
24.03 Speed error filtered Real -30000.0…30000.0 rpm 100 = 1 rpm
24.04 Speed error inverted Real -30000.0…30000.0 rpm 100 = 1 rpm
24.11 Speed correction Real -10000.00…10000.00 rpm 100 = 1 rpm
24.12 Speed error filter time Real 0…10000 ms 1 = 1 ms
25 Speed control
25.01 Torque reference speed
control
Real -1600.0…1600.0 % 10 = 1%
25.02 Speed proportional gain Real 0.00…250.00 - 100 = 1
25.03 Speed integration time Real 0.00…1000.00 s 100 = 1 s
25.04 Speed derivation time Real 0.000…10.000 s 1000 = 1 s
25.05 Derivation filter time Real 0…10000 ms 1 = 1 ms
25.06 Acc comp derivation time Real 0.00…1000.00 s 100 = 1 s
No. Name Type Range Unit FbEq32
