ABB ACS380 Series User Manual

330 Additional parameter data
35.11 Temperature 1 source List 0…2, 5…7, 11…17 - 1 = 1
35.12 Temperature 1 fault limit Real -60 … 5000 °C or ohm, or
-76 … 9032 °F
°C, °F or
ohm
1 = 1 unit
35.13 Temperature 1 warning limit Real -60 … 5000 °C or ohm, or
-76 … 9032 °F
°C, °F or
ohm
1 = 1 unit
35.14 Temperature 1 AI source Analog src --1 = 1
35.21 Temperature 2 source List 0…2, 5…7, 11…17 - 1 = 1
35.22 Temperature 2 fault limit Real -60 … 5000 °C or ohm,
or -76 … 9032 °F
°C, °F or
ohm
1 = 1 unit
35.23 Temperature 2 warning limit Real -60 … 5000 °C or ohm,
or -76 … 9032 °F
°C, °F or
ohm
1 = 1 unit
35.24 Temperature 2 AI source Analog src --1 = 1
35.50 Motor ambient temperature Real -60…100 °C or
-75 … 212 °F
°C 1 = 1 °
35.51 Motor load curve Real 50…150 % 1 = 1%
35.52 Zero speed load Real 50…150 % 1 = 1%
35.53 Break point Real 1.00 … 500.00 Hz 100 = 1 Hz
35.54 Motor nominal temperature
rise
Real 0…300 °C or 32…572 °F °C or °F 1 = 1°
35.55 Motor thermal time const Real 100…10000 s 1 = 1 s
36 Load analyzer
36.01 PVL signal source Analog src --1 = 1
36.02 PVL filter time Real 0.00…120.00 s 100 = 1 s
36.06 AL2 signal source Analog src --1 = 1
36.07 AL2 signal scaling Real 0.00…32767.00 - 100 = 1
36.09 Reset loggers List 0…3 - 1 = 1
36.10 PVL peak value Real -32768.00…32767.00 - 100 = 1
36.11 PVL peak date Data --1 = 1
36.12 PVL peak time Data --1 = 1
36.13 PVL current at peak Real -32768.00…32767.00 A 100 = 1 A
36.14 PVL DC voltage at peak Real 0.00…2000.00 V 100 = 1 V
36.15 PVL speed at peak Real -30000… 30000 rpm 100 = 1 rpm
36.16 PVL reset date Data --1 = 1
36.17 PVL reset time Data --1 = 1
36.20 AL1 0 to 10% Real 0.00…100.00 % 100 = 1%
36.21 AL1 10 to 20% Real 0.00…100.00 % 100 = 1%
36.22 AL1 20 to 30% Real 0.00…100.00 % 100 = 1%
36.23 AL1 30 to 40% Real 0.00…100.00 % 100 = 1%
36.24 AL1 40 to 50% Real 0.00…100.00 % 100 = 1%
36.25 AL1 50 to 60% Real 0.00…100.00 % 100 = 1%
36.26 AL1 60 to 70% Real 0.00…100.00 % 100 = 1%
36.27 AL1 70 to 80% Real 0.00…100.00 % 100 = 1%
36.28 AL1 80 to 90% Real 0.00…100.00 % 100 = 1%
No. Name Type Range Unit FbEq32
