338 Additional parameter data
58.02 Protocol ID Real 0…65535 - 1 = 1
58.03 Node address
Node ID
Real 0…255 - 1 = 1
58.04 Baud rate List 0…7 - 1 = 1
58.05 Parity List 0…3 - 1 = 1
58.06 Communication control List 0…2 - 1 = 1
58.07 Communication diagnostics PB 0000h…FFFFh - 1 = 1
58.08 Received packets Real 0…4294967295 - 1 = 1
58.09 Transmitted packets Real 0…4294967295 - 1 = 1
58.10 All packets Real 0…4294967295 - 1 = 1
58.11 UART errors Real 0…4294967295 - 1 = 1
58.12 CRC errors Real 0…4294967295 - 1 = 1
58.14 Communication loss action List 0…4 - 1 = 1
58.15 Communication loss mode List 0…2 - 1 = 1
58.16 Communication loss time Real 0.0…6000.0 s 10 = 1 s
58.17 Transmit delay Real 0…65535 ms 1 = 1 ms
58.18 EFB control word PB 0...FFFFFFFFh - 1 = 1
58.19 EFB status word PB 0...FFFFFFFFh - 1 = 1
58.22 CANopen NMT state List 0...127 - 1 = 1
58.23 Configuration location List 0...1 - 1 = 1
58.24 Transparent 16 scale Real 0...65535 - 1 = 1
58.25 Control profile List 0, 5, 7, 8, 9 - 1 = 1
58.26 EFB ref1 type List 0…5 - 1 = 1
58.27 EFB ref2 type List 0…5 - 1 = 1
58.28 EFB act1 type List 0…5 - 1 = 1
58.29 EFB act2 type List 0…5 - 1 = 1
58.31 EFB act1 transparent source Analog src --1 = 1
58.32 EFB act2 transparent source Analog src --1 = 1
58.33 Addressing mode List 0…2 - 1 = 1
58.34 Word order List 0…1 - 1 = 1
58.70 EFB debug mode List -100000...100000 - 1 = 1
58.71 EFB reference 1 Real -100000...100000 - 1 = 1
58.72 EFB reference 2 Real -100000...100000 - 1 = 1
58.73 EFB actual value 1 Real -100000...100000 - 1 = 1
58.74 EFB actual value 2 Real -100000...100000 - 1 = 1
58.76 RPDO1 COB-ID Real 0...7FFh - 1 = 1
58.77 RPDO1 transmission type Real 0...255 - 1 = 1
58.78 RPDO1 event timer Real 0...65535 ms 1 = 1 ms
58.79 TPDO1 COB-ID Real 0...7FFh - 1 = 1
58.80 TPDO1 transmission type Real 0...255 - 1 = 1
58.81 TPDO1 event timer Real 0...65535 ms 1 = 1 ms
No. Name Type Range Unit FbEq32
