Parameters 117
06.11 Main status word Main status word of the drive.
The bit assignments are described on page 468. The
related control word and state diagram are presented on
pages 467 and 470 respectively.
This parameter is read-only.
-
0000h...FFFFh Main status word. 1 = 1
06.16 Drive status word 1 Drive status word 1.
This parameter is read-only.
-
0000h…FFFFh Drive status word 1. 1 = 1
No. Name/Value Description Def/
FbEq16
Bit Name Description
0 Enabled 1 = Both run enable (see par. 20.12) and start
enable (20.19) signals are present. Note: This bit
is not affected by the presence of a fault.
1 Inhibited 1 = Start inhibited. See parameters 06.18 for the
source of the inhibiting signal.
2 DC charged 1 = DC circuit has been charged
3 Ready to start 1 = Drive is ready to receive a start command
4 Following reference 1 = Drive is ready to follow given reference
5 Started 1 = Drive has been started
6 Modulating 1 = Drive is modulating (output stage is being
controlled)
7 Limiting 1 = Any operating limit (speed, torque, etc.) is
active
8 Local control 1 = Drive is in local control
9 Network ctrl 1 = Drive is in network control (see page 14)
10 Ext1 active 1 = Control location EXT1 active
11 Ext2 active 1 = Control location EXT2 active
12 Reserved
13 Start request 1 = Start requested
14...15 Reserved
