ABB ACS880 PCP User Manual

150 Parameters
14.03 Module 1 status Displays the status of I/O extension module 1. No option
No option No module detected in the specified slot. 0
No communication A module has been detected but cannot be communicated
with.
1
Unknown The module type is unknown. 2
FIO-01 An FIO-01 module has been detected and is active. 15
FIO-11 An FIO-11 module has been detected and is active. 20
FAIO-01 An FAIO-01 module has been detected and is active. 24
14.05 DIO status (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Displays the status of the digital input/outputs on the
extension module. The activation/deactivation delays (if
any are specified) are ignored. A filtering time (for input
mode) can be defined by parameter 10.51 DI filter time.
Bit 0 indicates the status of DIO1.
Note: The number of active bits in this parameter depends
on the number of digital input/outputs on the extension
module.
Example: 1001b = DIO1 and DIO4 are on, remainder are
off.
This parameter is read-only.
-
0000b…1111b Status of digital in put/ou tputs. 1 = 1
14.06 DIO delayed status (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Displays the delayed status of the digital input/outputs on
the extension module. This word is updated only after
activation/deactivation delays (if any are specified).
Bit 0 indicates the status of DIO1.
Note: The number of active bits in this parameter depends
on the number of digital input/outputs on the extension
module.
Example: 00001001b = DIO1 and DIO4 are on, remainder
are off.
This parameter is read-only.
-
0000b…1111b Delayed status of digital input/outputs. 1 = 1
14.08 DIO filter time (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Defines a filtering time for parameter 14.05 DIO status.
The filtering time will only affect the DIOs that are in input
mode.
10.0 ms
0.8...100.0 ms Filtering time for 14.05. 10 = 1 ms
14.09 DIO1 function (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Selects whether DIO1 of the extension module is used as
a digital input or output.
Input
Output DIO1 is used as a digital output. 0
Input DIO1 is used as a digital input. 1
14.11 DIO1 output source (Visible when 14.01 Module 1 type = FIO-01 or
FIO-11)
Selects a drive signal to be connected to digital
input/output DIO1 of the extension module when
parameter 14.09 DIO1 function is set to Output.
Not energized
Not energized Output is not energized. 0
Energized Output is energized. 1
No. Name/Value Description Def/
FbEq16

ABB ACS880 PCP Specifications

General

Output current	Up to 5200 A
Input voltage	380-690 V
Power range	5600 kW
Cooling method	Air or liquid
Protection class	IP21, IP54
Communication interfaces	Ethernet, CANopen
