Parameters 325
90.61 Gear numerator Parameters 90.61 and 90.62 define a gear function
between the motor and load speeds.
1
-2147483648
…2147483647
Gear numerator (motor-side). -
90.62 Gear denominator See parameter 90.61 Gear numerator.1
-2147483648
…2147483647
Gear denominator (load-side). -
90.63 Feed constant
numerator
Parameters 90.63 and 90.64 define the feed constant for
the position calculation:
The feed constant converts rotational motion into
translatory motion. The feed constant is the distance the
load moves during one turn of the motor shaft.
The translatory load position is shown by parameter 90.05
Load position scaled.
1
-2147483648
…2147483647
Feed constant numerator. -
90.64 Feed constant
denominator
See parameter 90.63 Feed constant numerator.1
-2147483648
…2147483647
Feed constant denominator. -
90.65 Pos counter init value Defines an initial position (or distance) for the position
counter (as a decimal number) when parameter 90.66 Pos
counter init value source is set to Pos counter init value.
See also section Position counter (page 66).
The number of decimal places is defined by parameter
90.38 Pos counter decimals.
0.000
-2147483.648
…2147483.647
Initial value for position counter. -
90.66 Pos counter init value
source
Selects the source of the initial position value. When the
source selected by 90.67 Pos counter init cmd source
activates, the value selected in this parameter is assumed
to be the position of the load (in decimal format).
Pos counter
init value
Zero 0. 0
Pos counter init value Parameter 90.65 Pos counter init value.1
Other Source selection (see Terms and abbreviations on
page 101).
-
No. Name/Value Description Def/
FbEq16
90.61 Gear numerator
90.62 Gear denominator
Motor speed
Load speed
=
90.63 Feed constant numerator
90.64 Feed constant denominator
