Fault tracing 419
AFE1 Emergency stop (off2) Drive has received an
emergency stop (mode
selection off2) command.
Check that it is safe to continue
operation.
Return emergency stop push button to
normal position.
Restart drive.
AFE2 Emergency stop (off1 or
off3)
Drive has received an
emergency stop (mode
selection off1 or off3)
command.
AFEA Enable start signal
missing
(Editable message text)
No enable start signal
received.
Check the setting of (and the source
selected by) parameter 20.19 Enable
start command.
AFEB Run enable missing No run enable signal is
received.
Check setting of parameter 20.12 Run
enable 1 source. Switch signal on (e.g.
in the fieldbus Control Word) or check
wiring of selected source.
AFEC External power signal
missing
95.04 Control board
supply is set to External
24V but no voltage is
connected to the XPOW
connector of the control
unit.
Check the external 24 V DC power
supply to the control unit, or change the
setting of parameter 95.04.
AFF6 Identification run Motor ID run will occur at
next start.
Informative warning.
AFF7 Autophasing Autophasing will occur at
next start.
Informative warning.
B5A0 STO event
Programmable event: 31.22
STO indication run/stop
Safe torque off function
is active, i.e. safety
circuit signal(s)
connected to connector
XSTO is lost.
Check safety circuit connections. For
more information, see appropriate
drive hardware manual and
description of parameter 31.22 STO
indication run/stop (page 245).
D200 Overtemperature 09.10 Measured
temperature exceeded
79.07 Warning
temperature limit for 5
sec or the Klixon digital
input
is false.
Check for problem in measurement
device.
Check for problem in temperature
measurement circuit.
Check well and discharge pressures
(excessive pressure can cause
heating).
Check warning function setting in
parameters.
D201 Pressure 09.09 Pressure
exceeded 76.07 Analog
feedback limit for 76.08
Analog feedback limit
delay time or 76.04
Digital feedback source
is set as false.
Check for problem in measurement
device.
Check for high gas content.
Check warning function setting in
parameters.
D202 Underload 78.02 Underload function
is set to warning when
09.01 Rod torque and
09.05 Rod speed actual
values are lower than
user defined curve
(parameters 78.03 -
78.08) for 78.09
Underload delay time.
Check parameter settings.
Check setting of 78.02 Underload
function.
Code
(hex)
Warning Cause What to do
