ABB DCS 500B User Manual

DCS500 Pin and Parameter list
A 12
Group 2: ANALOG OUTPUTS
AO1.[IN]
Input IN of AO1 function block ( S5/16 ).
Connected to signal which is needed in AO1.
201 FB_I: C4 SC: - HL: 19999 LL: 0 D: 12102 U: -
AO1_NOMINAL_V
Parameter of AO1 function block ( S5/16 ).
Output voltage which corresponds to nominal value of selected signal.
202 FB_P: I2 SC: 1 HL: 10000 LL: 0 D: 10000 U: mV
AO1_OFFSET_V
Parameter of AO1 function block ( S5/16 ).
Offset voltage which is added to the output voltage.
203 FB_P: I2 SC: 1 HL: 10000 LL: -10000 D: 0 U: mV
AO1_NOMINAL_VAL
Parameter of AO1 function block ( S5/16 ).
The nominal value of the signal which is connected to the IN-input.
204 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 20000 U: -
AO2.[IN]
Input IN of AO2 function block ( S2/16 )
Connected to signal which is needed in AO2.
205 FB_I: C4 SC: - HL: 19999 LL: 0 D: 10505 U: -
AO2_NOMINAL_V
Parameter of AO2 function block ( S2/16 )
Output voltage which corresponds to nominal value of selected signal.
206 FB_P: I2 SC: 1 HL: 10000 LL: 0 D: 5000 U: mV
AO2_OFFSET_V
Parameter of AO2 function block ( S2/16 )
Offset voltage which is added to the output voltage.
207 FB_P: I2 SC: 1 HL: 10000 LL: -10000 D: 0 U: mV
AO2_NOMINAL_VAL
Parameter of AO2 function block ( S2/16 )
The nominal value of the signal which is connected to the IN-input.
208 FB_P: I2 SC: 1 HL: 32767 LL: 0 D: 4095 U: -
DATASET2.[IN1]
Input of DATASET2 function block ( S12/16 )
DATASET 2 is used for data transmission from the drive to the fieldbus master.
When a fieldbus communication module is connected the DCS 500 can transmit a
3 word telegram called DATASET2.[IN1]…[IN3] to a fieldbus master.
DATASET2.[IN1] selects the address of first word of this telegram.
209 FB_I: C4 SC: - HL: 19999 LL: 0 D: 0 U: -
DATASET2.[IN2]
Input of DATASET2 function block ( S12/16 )
DATASET2.[IN2] selects the address of second word of this telegram.
210 FB_I: C4 SC: - HL: 19999 LL: 0 D: 0 U: -
DATASET2.[IN3]
Input of DATASET2 function block ( S12/16 )
DATASET2.[IN3] selects the address of third word of this telegram.
211 FB_I: C4 SC: - HL: 19999 LL: 0 D: 0 U: -
