DCS500 Pin and Parameter list
A 52
Group 20: SPEED CONTROLLER
ERR.[IN]
Input of SPEED_ERROR-function block. ( S5/16 )
Speed reference value for speed error calculation.
2001 FB_I: C4 SC: SPEED HL: 19999 LL: 0 D: 11802 U: -
ERR.[STEP]
Input of SPEED_ERROR-function block. ( S5/16 )
Speed step value which is added to speed error.
2002 FB_I: C4 SC: SPEED HL: 19999 LL: 0 D: 12517 U: -
ERR.[WIN_MODE]
Input of SPEED_ERROR-function block. ( S5/16 )
Selection for window control mode.
2003 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
ERR.WIN_SIZE
Parameter of SPEED_ERROR-function block. ( S5/16 )
Size of the speed error window in window control mode.
2004 FB_P: I2 SC: SPEED HL: 20000 LL: 0 D: 0 U: rpm
ERR.FRS
Parameter of SPEED_ERROR-function block. ( S5/16 )
The time constant of speed difference filter.
2005 FB_P: I2 SC: 1 HL: 1000 LL: 0 D: 0 U: ms
SPC.[IN]
Input of SPEED_CONTROL-function block. ( S5/16 )
Speed error input.
2006 FB_I: C4 SC: SPEED HL: 19999 LL: 0 D: 12001 U: -
SPC.[RINT]
Input of SPEED_CONTROL-function block. ( S5/16 )
Command to reset the integral part of speed controller.
2007 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
SPC.[BAL]
Input of SPEED_CONTROL-function block. ( S5/16 )
Command to set the integral part of the speed controller to the value at SPC.[BALREF].
2008 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
SPC.[BALREF]
Input of SPEED_CONTROL-function block. ( S5/16 )
External value for the integral part of the speed controller when external setting is used via
SPC.[BAL].
2009 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 0 U: -
SPC.[BAL2]
Input of SPEED_CONTROL-function block. ( S5/16 )
Command to set the integral part of the speed controller to the value at SPC.[BAL2REF].
2010 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 12403 U: -
SPC.[BAL2REF]
Input of SPEED_CONTROL-function block. ( S5/16 )
External value for the integral part of the speed controller when external setting is used via
SPC.[BAL2].
2011 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 12402 U: -
