DCS500 Pin and Parameter list
A 109
Group 124: TORQUE REFERENCE CHAIN
SEL1:OUT
Signal of TORQ_REF_SELECTION-function block ( S6/16 )
Torque reference from torque reference chain .
12401 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
SEL2:OUT
Signal of TORQ_REF_HANDLING-function block ( S7/16 )
Torque reference after torque reference selector .
12402 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
SEL2:TORQ/SPEED
Signal of TORQ_REF_HANDLING-function block ( S7/16 )
An output indicating which control mode is active:
0 = speed control is active
-1 = torque control is active.
12403 FB_O: B SC: BO HL: - LL: - D: - U: -
SEL2:IN_LIM
Signal of TORQ_REF_HANDLING-function block ( S7/16 )
An output indicating that torque reference is in limit:
0 = reference between limits
-1 = reference has reached limit / is limited
12404 FB_O: B SC: BO HL: - LL: - D: - U: -
