DCS500 Pin and Parameter list
A 98
Group 113: MOTOR 1 FIELD
F1_CURR_REF
Signal of MOTOR_1_FIELD- function block. ( S8/16 )
Field current reference for field exciter no. 1.
11301 FB_O: I2 SC: FCURR HL: - LL: - D: - U: A
F1_CURR_ACT
Signal of MOTOR_1_FIELD- function block. ( S8/16 )
Actual field current from field exciter no. 1.
11302 FB_O: I2 SC: FCURR HL: - LL: - D: - U: A
REF_DCF
Signal of DCF FIELDMODE function block. (S2/16 | S21.232)
Only activ if DCF MODE (1215) = FEXLINK NODE1 or FEXLINK NODE2
Field current reference via FEXLINK for DCF500 as field exciter no. 1 or no. 2
11303 FB_O: I2 SC:MCURR HL: - LL: - D: - U: A
