DCS500 Pin and Parameter list
A 114
Group 135: DDCTool
STATUS_WORD
Signal of DDCTool interface. DCS 500 drive status word:
B0 reserved
B1 RDY ON 1=ready to close the contactor
B2 RDY RUN 1=ready to generate torque
B3 RUNNING 1=speed/torque control operating
B4 Auto-reclosing 1=A140 is activ
B5 FAULT 1=indication of a fault in DCS500
B6 ALARM 1=indication of an alarm in DCS500
B7 reserved
B8 reserved
B9 reserved
B10 reserved
B11 reserved
B12 reserved
B13 reserved
B14 Emergency stop 1=A102 is not activ, [EME_STOP](906)="0"
B15 Start inhibition 1=A101 is activ, [START_INHIBIT](908)="1"
13501 S: PB SC: - HL: - LL: - D: - U: -
LTIME
Signal of DDCTool interface.
DCS 500 time counter.
13502 S: I4 SC: - HL: - LL: - D: - U: -
LDATE
Signal of DDCTool interface.
DCS 500 date counter.
13503 S: I4 SC: - HL: - LL: - D: - U: -
