ABB DCS 500B User Manual

Functional Software Description
DCS 500 Software Description 1
• General
The DC drive named DCS 500B is equipped with a SDCS-CON-2
microprocessor board. The original version was called DCS 500
and was equipped with a SDCS-CON-1 board.
The DCS 500B has a MODBUS communication bus connection,
which is a common bus protocol for ABB Drives products for the
panel link.
The DCS 500B drive can be controlled by means of digital and
analog inputs or via the CDP 312 Control Panel.
The DCS 500B software contains the function blocks of a standard
application program and function blocks which can be connected
to each other to form more advanced application programs. A
standard program is designed so that it contains numerous func-
tions, is flexible and suitable for most of the basic drive applica-
tions.
Typical application areas for DCS 500B are:
• Winder control
• Master Follower
• Positioning Control
• Ski Lifts
• Battery Charging
• Cranes
0
TG
6SHHG
FRQWUROOHU
&XUUHQW&RQWURO
)LULQJXQLW
'&02725
6SHHG$FWXDO
6FDOLQJ
&XUUHQWDFWXDO
IRUPLQJ
5DPS
JHQHUDWRU
(0)
FDOF
$&VXSSO\
Up
Down
Constant
sources
6SHHG
UHIHUQFH
7RUTXHUHIHUHQFH
$OSKDUHI
&XUUHQWOLPLWDWLRQ
7RUTXH
UHIHUHQFH
VHOHFWRU
/RF5HP
6SHHGUHIHUHQFH
YLDSDQHOEXV
DGG6SHHG
UHIHUHQFH
Figure 1 DCS 500B armature control
