ABB DCS 500B User Manual

DCS500 Pin and Parameter list
A 102
Group 117: RAMP GENERATOR
RAMP:OUT
Signal of RAMP GENERATOR- function block. ( S4/16 )
Speed reference after ramp function.
11701 FB_O: I2 SC: SPEED HL: - LL: - D: - U: rpm
ACCELCOMP:OUT
Signal of RAMP GENERATOR- function block. ( S4/16 )
Acceleration compensation. Additional torque reference output calculated from the
ACC_COMP.TRMIN (1719) parameter.
11702 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
RAMP:SIGN
Signal of RAMP GENERATOR- function block. ( S4/16 )
Sign of speed reference after ramp function.
11703 FB_O: I2 SC: - HL: - LL: - D: - U: -
