ABB DCS 500B User Manual

DCS500 Pin and Parameter list
A 49
Group 19: REFERENCE SOURCES
CONST_REF.[ACT1]
Input of CONST_REF-function block. ( S4/16 )
Selects the constant reference REF1 to block output.
ACT1 overrides other ACT-inputs.
1901 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
CONST_REF.[ACT2]
Input of CONST_REF-function block. ( S4/16 )
Selects the constant reference REF2 to block output.
ACT2 overrides ACT3- and ACT4-inputs.
1902 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
CONST_REF.[ACT3]
Input of CONST_REF-function block. ( S4/16 )
Selects the constant reference REF3 to block output.
ACT3 overrides ACT4-input.
1903 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
CONST_REF.[ACT4]
Input of CONST_REF-function block. ( S4/16 )
Selects the constant reference REF4 to block output.
1904 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
CONST_REF.DEF
Parameter of CONST_REF-function block. ( S4/16 )
This value is selected when none of four ACT-inputs is active.
1905 FB_P: I2 SC: SPEED HL: 32767 LL: -32767 D: 1000 U: rpm
CONST_REF.REF1
Parameter of CONST_REF-function block. ( S4/16 )
This speed reference is selected when ACT1-input is active.
1906 FB_P: I2 SC: SPEED HL: 32767 LL: -32767 D: 1500 U: rpm
CONST_REF.REF2
Parameter of CONST_REF-function block. ( S4/16 )
This speed reference is selected when ACT2-input is active.
1907 FB_P: I2 SC: SPEED HL: 32767 LL: -32767 D: 0 U: rpm
CONST_REF.REF3
Parameter of CONST_REF-function block. ( S4/16 )
This speed reference is selected when ACT3-input is active.
1908 FB_P: I2 SC: SPEED HL: 32767 LL: -32767 D: 0 U: rpm
CONST_REF.REF4
Parameter of CONST_REF-function block. ( S4/16 )
This speed reference is selected when ACT4-input is active.
1909 FB_P: I2 SC: SPEED HL: 32767 LL: -32767 D: 0 U: rpm
REFSEL.[IN1]
Input of REF_SEL-function block. ( S4/16 )
Speed reference input which is selected with SEL1-input.
1910 FB_I: C4 SC: SPEED HL: 19999 LL: 0 D: 10104 U: -
REFSEL.[SEL1]
Input of REF_SEL-function block. ( S4/16 )
Selects the speed reference input IN1 to the output.
1911 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 10715 U: -
