DCS500 Pin and Parameter list
A 46
Group 17: RAMP GENERATOR
RAMP.[IN]
Input of RAMP GENERATOR-function block. ( S4/16 )
Source for the speed reference.
1701 FB_I: C4 SC: SPEED HL: 19999 LL: 0 D: 11903 U: -
RAMP.[RES_IN]
Input of RAMP GENERATOR-function block. ( S4/16 )
Used to set ramp input to zero.
1702 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
RAMP.[HOLD]
Input of RAMP GENERATOR-function block. ( S4/16 )
Used to hold the present ramp output value .
1703 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
RAMP.[FOLLOW_IN]
Input of RAMP GENERATOR-function block. ( S4/16 )
Used to make the ramp output to follow the ramp input value.
1704 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
RAMP.[FOLL_ACT]
Input of RAMP GENERATOR-function block. ( S4/16 )
Used to make the ramp output to follow the signal at RAMP.[SPEED_SET],
connected to SPEED ACT (12102) by default.
1705 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
RAMP.[RES_OUT]
Input of RAMP GENERATOR-function block. ( S4/16 )
Used to set ramp output to zero.
1706 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
RAMP.[T1/T2]
Input of RAMP GENERATOR-function block. ( S4/16 )
Selects the used set of ramp times:
0 = ACCEL1, DECEL1 and SMOOTH1 are used
<> 0 = ACCEL2, DECEL2 and SMOOTH2 are used.
1707 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
ACCEL1
Parameter of RAMP GENERATOR-function block. ( S4/16 )
The time in which the drive will accelerate from zero speed to nominal speed.
1708 FB_P: I2 SC: 0.1 HL: 30000 LL: 1 D: 200 U: s
DECEL1
Parameter of RAMP GENERATOR-function block. ( S4/16 )
The time in which the drive will decelerate from nominal speed to zero speed.
1709 FB_P: I2 SC: 0.1 HL: 30000 LL: 1 D: 200 U: s
SMOOTH1
Parameter of RAMP GENERATOR-function block. ( S4/16 )
The speed ramp output softening time (S-RAMP function).
The total time how long the softening function will last.
1710 FB_P: I2 SC: 1 HL: 20000 LL: 0 D: 0 U: ms
ACCEL2
Parameter of RAMP GENERATOR-function block. ( S4/16 )
The time in which the drive will accelerate from zero speed to nominal speed.
1711 FB_P: I2 SC: 0.1 HL: 30000 LL: 1 D: 100 U: s
