DCS500 Pin and Parameter list
A 79
Group 104: CURRENT CONTROL
ARM_ALPHA
Signal of CURRENT CONTROL-function block ( S7/16 ).
Firing angle.
10401 FB_O: I2 SC: 1 HL: - LL: - D: - U: -.
ARM_DIR
Signal of CURRENT CONTROL-function block ( S7/16 ).
Identification of the bridge currently in use:
0 = NO BRIDGE
1 = MOTOR BRIDGE
2 = GENERATOR BRIDGE
10402 FB_O: E2 SC: - HL: - LL: - D: - U: -
CURR_REF_IN_LIM
Signal of CURRENT CONTROL-function block ( S7/16 ).
Status signal indicating that the current reference is in limit:
0 = current reference is not in limit
-1 = current reference is in limit.
10403 FB_O: B SC: BO HL: - LL: - D: - U: -
CURR_DER_IN_LIM
Signal of CURRENT CONTROL-function block ( S7/16 ).
Status signal indicating that the rate of change of the current reference is too high:
0 = current reference is not in limit
-1 = rate of change of current reference is in limit.
10404 FB_O: B SC: BO HL: - LL: - D: - U: -
ARM_CURR_REF
Signal of CURRENT CONTROL-function block ( S7/16 ).
Either current or torque reference is use depending on value of REF_TYPE_SEL (405).
10405 FB_O: I2 SC: MCURR HL: - LL: - D: - U: A
