DCS500 Pin and Parameter list
A 57
Group 23: TORQUE and CURRENT LIMITS
[SPC_TORQ_MAX]
Input of TORQUE/CURRENT_LIMITATION-function block. ( S6/16 )
Maximum torque limit for the speed controller.
Can be connected to analog input or function block output.
2301 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 12510 U: -
[SPC_TORQ_MIN]
Input of TORQUE/CURRENT_LIMITATION-function block. ( S6/16 )
Minimum torque limit for the speed controller.
Can be connected to analog input or function block output.
2302 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 12511 U: -
[TREF_TORQ_MAX]
Input of TORQUE/CURRENT_LIMITATION-function block. ( S6/16 )
Maximum torque limit for the torque reference chain.
Can be connected to analog input or function block output.
2303 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 12510 U: -
[TREF_TORQ_MIN]
Input of TORQUE/CURRENT_LIMITATION-function block. ( S6/16 )
Minimum torque limit for the torque reference chain.
Can be connected to analog input or function block output.
2304 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 12511 U: -
TORQ_MAX
Parameter of TORQUE/CURRENT_LIMITATION-function block. ( S6/16 )
Maximum torque limit for the drive.
2305 FB_P: I2 SC: TORQ HL: 16000 LL: 20 D: 4000 U: %
TORQ_MIN
Parameter of TORQUE/CURRENT_LIMITATION-function block. ( S6/16 )
Minimum torque limit for the drive.
2306 FB_P: I2 SC: TORQ HL: -20 LL: -16000 D: -4000 U: %
ARM_CURR_LIM_P
Parameter of TORQUE/CURRENT_LIMITATION-function block. ( S6/16 )
Maximum current of the motor bridge.
2307 FB_P: I2 SC: MCURR HL: 16383 LL: 0 D: 4095 U: A
ARM_CURR_LIM_N
Parameter of TORQUE/CURRENT_LIMITATION-function block. ( S6/16 )
Maximum current of the generator bridge.
2308 FB_P: I2 SC: MCURR HL: 0 LL: -16383 D: -4095 U: A
