DCS500 Pin and Parameter list
A 30
Group 10: EMF CONTROL
FIELD_MODE
Parameter of EMF CONTROL-function block. ( S8/16 )
Selects the operating mode of motor field control:
0 = CONSTANT FIELD No EMF-control (constant field) without field
reversal.
1 = EMF, NO FIELD REV EMF-control without field reversal.
2 = NO EMF, FIELD REV No EMF-control (constant field) with field
reversal.
3 = EMF+FIELD REV EMF-control with field reversal.
4 = NO EMF, OPTITORQUE OPTITORQUE without EMF-control.
5 = EMF+OPTITORQUE OPTITORQUE with EMF-control.
1001 FB_P: E2 SC: - HL: 5 LL: 0 D: 0 U: -
[FLUX_REF]
Input of EMF CONTROL-function block. ( S8/16 )
This is an input for flux reference. EMF CONTROL-block is using either flux or EMF
reference.
1002 FB_I: C4 SC: FLUX HL: 19999 LL: 0 D: 12512 U: -
[EMF_REF]
Input of EMF CONTROL-function block. ( S8/16 )
This is an input for EMF reference. EMF CONTROL-block is using either flux or EMF
reference.
1003 FB_I: C4 SC: EMF HL: 19999 LL: 0 D: 12509 U: -
[FLUX_REF_SEL]
Input of EMF CONTROL-function block. ( S8/16 )
This is an input for flux reference selection. It will select either [FLUX_REF] input or
constant reference of 100%.
0 = internal reference
<>0 = [FLUX_REF] input.
1004 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
[EMF_REF_SEL]
Input of EMF CONTROL-function block. ( S8/16 )
This is an input for EMF reference selection. It will select either [EMF_REF] input or
LOCAL_EMF_REF-parameter.
0 = LOCAL_EMF_REF-parameter
<>0 = [EMF_REF] input.
1005 FB_I: C4 SC: BI HL: 19999 LL: 0 D: 0 U: -
LOCAL_EMF_REF
Parameter of EMF CONTROL-function block. ( S8/16 )
Sets the value of local EMF reference.
1006 FB_P: I2 SC: 1 HL: 150 LL: 0 D: 100 U: %
EMF_KP
Parameter of EMF CONTROL-function block. ( S8/16 )
Proportional gain of the EMF controller. Gain is reduced above field weakening point with
a factor 1/n to keep the process gain constant. Scaling:
150 = gain is 54 %
277 = gain is 100 %.
1007 FB_P: I2 SC: 1 HL: 999 LL: 1 D: 150 U: -
