DCS500 Pin and Parameter list
A 60
Group 24: TORQUE REFERENCE CHAIN
SEL1.[TREF_A]
Input of TORQ_REF_SELECTION-function block. ( S6/16 )
Torque reference A is connected to this input.
2401 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 10107 U: -
SEL1.TREF_A_FTC
Parameter of TORQ_REF_SELECTION-function block. ( S6/16 )
Filter time constant for torque reference A.
2402 FB_P: I2 SC: 1 HL: 1000 LL: 0 D: 0 U: ms
SEL1.[LOAD_SHARE]
Input of TORQ_REF_SELECTION-function block. ( S6/16 )
Load share is connected to this input.
Load share is used to scale the torque reference A.
SEL1:OUT = SEL1.[LOAD_SHARE] * SEL1.TREF_A_FTC / 4000
2403 FB_I: C4 SC: - HL: 19999 LL: 0 D: 12521 U: -
SEL1.[TREF_B]
Input of TORQ_REF_SELECTION-function block. ( S6/16 )
Torque reference B is connected to this input.
2404 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 12519 U: -
SEL1.TREF_B_SLOPE
Parameter of TORQ_REF_SELECTION-function block. ( S6/16 )
The slope of the ramp for torque reference B.
Given as the time from 0 to 100 % torque.
2405 FB_P: I2 SC: 1 HL: 10000 LL: 0 D: 0 U: ms
SEL2.TREF_SEL
Parameter of TORQ_REF_HANDLING-function block. ( S7/16 )
Selection for the source of torque reference:
0 = NONE
1 = SPEED_CONTROLLED (from TREF_SPC)
2 = EXT.TORQUE REF (from TREF_EXT)
3 = MIN (minimum logic with speed error comparison)
4 = MAX (maximum logic with speed error comparison)
5 = WINDOW (window control mode)
2406 FB_P: E2 SC: - HL: 5 LL: 0 D: 1 U: -
SEL2.[TREF_SPC]
Input of TORQ_REF_HANDLING-function block. ( S7/16 )
Torque reference from speed controller is connected to this input.
2407 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 12004 U: -
SEL2.[TREF_EXT]
Input of TORQ_REF_HANDLING-function block. ( S7/16 )
External torque reference is connected to this input.
2408 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 12401 U: -
SEL2.[TORQ_STEP]
Input of TORQ_REF_HANDLING-function block. ( S7/16 )
Torque step is connected to this input.
2409 FB_I: C4 SC: TORQ HL: 19999 LL: 0 D: 12520 U: -
