DCS500 Pin and Parameter list
A 18
Group 5: CONVERTER AND MOTOR
U_MOTN_V
Parameter of SETTINGS-function block (S2/16 | mod in S21.232)
The nominal voltage of the motor in volts. (higher HL in S21.232)
501 FB_P: I2 SC: 1 HL: 1800 LL: 0 D: 0 U: V
I_MOTN_A
Parameter of SETTINGS-function block. ( S2/16 )
The nominal current of the motor in amperes is set by this parameter for 6 pulse drives.
Half of the nominal current of the motor in A is set by this parameter for 12 pulse drives!
Notice that when this value is changed, all motor current parameters and signals
will have different values when they are shown in [A] in the panel or in
CMT/DCS 500:
ARM_CURR_REF_SLP, CURRENT_RISE_MAX, MODEL1.CURR,
MODEL2.CURR, ARM_CURR_LIM_P, ARM_CURR_LIM_N,
MAX_CURR_LIM_N1-5, ARM_CURR_REF, ARM_CURR_ACT,
REF_DCF, CURR_LIM_P, CURR_LIM_N,
Arm.Curr.Slave, Arm.CURR.Both, Curr.-Ref.1,
Curr.-Ref.2.
502 FB_P: I2 SC: 1 HL: 10000 LL: 0 D: 0 U: A
I_MOT1_FIELDN_A
Parameter of SETTINGS-function block (S2/16 | mod in S21.232)
The nominal field current of motor 1 in 0.01 Amperes. (lower HL in S21.232)
Notice that when this value is changed, all motor 1 field current parameters and
signals will have different values when they are shown in [A] in the panel or in
CMT/DCS 500:
F1_CURR_GT_MIN_L, F1_OVERCURR_L, F1_RED.REF,
OPTI.REF_MIN_L, REV.REV_HYST,
F1_CURR_REF, F1_CURR_ACT.
503 FB_P: I2 SC: 0.01 HL: 16380 LL: 0 D: 30 U: A
I_MOT2_FIELDN_A
Parameter of SETTINGS-function block (S2/16 | mod in S21.232)
The nominal field current of motor 2 in 0.01 Amperes. (lower HL in S21.232)
Notice that when this value is changed, all motor 2 field current parameters and
signals will have different values when they are shown in [A] in the panel or in
CMT/DCS 500:
F2_CURR_GT_MIN_L, F2_OVERCURR_L, F2_RED.REF,
F2_CURR_REF, F2_CURR_ACT.
504 FB_P: I2 SC: 0.01 HL: 16380 LL: 0 D: 30 U: A
