DCS500 Pin and Parameter list
A 78
Group 103: BRAKE CONTROL
TREF_OUT
Signal of BRAKE_CONTROL-function block ( S10/16 )
Output for torque reference which is used when the brake is opened or closed.
Usually connected to input SPC.[BALREF] (2009) or SPC.[BAL2REF] (2011) of
SPEED_CONTROL-block.
10301 FB_O: I2 SC: TORQ HL: - LL: - D: - U: %
TREF_ENABLE
Signal of BRAKE_CONTROL-function block ( S10/16 )
Output which is active when the brake is opened or closed.
Usually connected to input SPC.[BAL] (2008) or SPC.[BAL2] (2010) of
SPEED_CONTROL-block:
0 = TREF_OUT = 0
-1 = TREF_OUT is set by BRAKE_CONTROL-block.
10302 FB_O: B SC: BO HL: - LL: - D: - U: -
DECEL_CMND
Signal of BRAKE_CONTROL-function block ( S10/16 )
Output which is active before the brake is closed:
0 = normal speed reference from application
-1 = command to set the speed reference to zero to stop the drive.
10303 FB_O: B SC: BO HL: - LL: - D: - U: -
LIFT_BRAKE
Signal of BRAKE_CONTROL-function block ( S10/16 )
Output which is used to open the brake when the motor is able to produce torque:
0 = brake is closed
-1 = lift the brake.
10304 FB_O: B SC: BO HL: - LL: - D: - U: -
BRAKE_RUN
Signal of BRAKE_CONTROL-function block ( S10/16 )
Output which is used to give a run-command to DRIVE LOGIC and reference selectors:
0 = no run-command
-1 = run-command active.
10305 FB_O: B SC: BO HL: - LL: - D: - U: -
