ABB DCS 500B User Manual

DCS500 Pin and Parameter list
A 110
Group 125: TASKS, CONSTANTS
CONSTANT 0
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which is always zero (FALSE).
12501 FB_O: I2 SC: - HL: 0 LL: 0 D: 0 U: -
CONSTANT -1
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which is always -1 (TRUE).
Can be connected to function block inputs (FB_I: B) which use BI scaling.
12502 FB_O: I2 SC: - HL: -1 LL: -1 D: -1 U: -
CONSTANT 1
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which is always 1.
12503 FB_O: I2 SC: - HL: 1 LL: 1 D: 1 U: -
CONSTANT 2
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which is always 2.
12504 FB_O: I2 SC: - HL: 2 LL: 2 D: 2 U: -
CONSTANT 10
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which is always 10.
12505 FB_O: I2 SC: - HL: 10 LL: 10 D: 10 U: -
CONSTANT 100
Signal of CONSTANTS-function block ( S2;S16/16 )
Value which is always 100.
12506 FB_O: I2 SC: - HL: 100 LL: 100 D: 100 U: -
CONSTANT 1000
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which is always 1000.
12507 FB_O: I2 SC: - HL: 1000 LL: 1000 D: 1000 U: -
CONSTANT 31416
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which is always 31416.
12508 FB_O: I2 SC: - HL: 31416 LL: 31416 D: 31416 U: -
EMF: 100%
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which corresponds to nominal EMF = 3786.
12509 FB_O: I2 SC: - HL: 3786 LL: 3786 D: 3786 U: -
TORQ: 100%
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which corresponds to nominal positive torque = 4000.
12510 FB_O: I2 SC: - HL: 4000 LL: 4000 D: 4000 U: -
TORQ -100%
Signal of CONSTANTS-function block ( S2,S16/16 )
Value which corresponds to nominal negative torque = -4000.
12511 FB_O: I2 SC: - HL: -4000 LL: -4000 D: -4000 U: -
