ABB FDNA-01 User Manual

Communication protocol 111
 ABB Drives profile with set speed assembly
The ABB Drives profile with set speed assembly is defined by
ABB. The format of the output assembly is:
17 DATA IN 6 Value (High Byte)
18 DATA IN 7 Value (Low Byte)
19 DATA IN 7 Value (High Byte)
20 DATA IN 8 Value (Low Byte)
21 DATA IN 8 Value (High Byte)
22 DATA IN 9 Value (Low Byte)
23 DATA IN 9 Value (High Byte)
24 DATA IN 10 Value (Low Byte)
25 DATA IN 10 Value (High Byte)
Instance 801
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reset Ramp
in
Zero
Ramp
Hold
Ramp
Out
Zero
Inhibit
Oper-
ation
Off 3
Control
Off 2
Control
Off 1
Control
1 Ext
Ctrl
Loc
Remote
Cmd
2 Set Speed (Low Byte)
3 Set Speed (High Byte)
Instance 173
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

ABB FDNA-01 Specifications

General

Brand	ABB
Model	FDNA-01
Category	Control Unit
Language	English
