ABB FDNA-01 User Manual

Communication protocol 151
Instance #2: FDNA-01 configuration parameters
group B (group 2)
The actual parameter group number depends on the drive type.
Group B (group 2) corresponds to
• parameter group 55 in ACS355
• parameter group 53 in ACSM1, ACS850 and ACQ810
• parameter group 53 in ACS880 if the adapter is installed as
fieldbus adapter A or group 56 if the adapter is installed as
fieldbus adapter B
.
28 Configuration Group
A (Group 1) –
Parameter 28
Get See 28 PAR TABLE
VER.
UINT16
29 Configuration Group
A (Group 1) –
Parameter 29
Get See 29 DRIVE TYPE
CODE.
UINT16
30 Configuration Group
A (Group 1) –
Parameter 30
Get See 30 MAPPING FILE
VER.
UINT16
31 Configuration Group
A (Group 1) –
Parameter 31
Get See 31 D2FBA COMM
STA.
UINT16
32 Configuration Group
A (Group 1) –
Parameter 32
Get See 32 FBA COMM SW
VER.
UINT16
33 Configuration Group
A (Group 1) –
Parameter 33
Get See 33 FBA APPL SW
VER.
UINT16
# Attribute name Services Description Data
type
1 Configuration Group B
(Group 2) – Parameter 1
Get, Set
See 01 DATA OUT 1.
UINT16
2 Configuration Group B
(Group 2) – Parameter 2
Get, Set
See 01 DATA OUT 1.
UINT16
# Attribute name Services Description Data
type
