28 Mechanical installation
Mounting the adapter module
The adapter module is to be inserted into its specific position in the
drive. The module is held in place with plastic pins and one screw.
The screw also provides the electrical connection between the
module and drive frame for cable shield termination.
When the module is installed, the signal and power connection to
the drive is made through a 20-pin connector. (All drives do not use
all the available signals so the connector on the drive may have
fewer pins.)
Mounting procedure:
1. Insert the module carefully into its position on the drive.
2. Fasten the screw.
Note: It is essential to install the screw properly to fulfill the EMC
requirements and to ensure the proper operation of the module.
For more information on mounting, see the drive manuals.
