ABB FDNA-01 User Manual

Technical data 161
DeviceNet link
Power supply Input voltage:
• From the drive: +3.3 V DC (+/- 5%)
• From the network: +24 V DC nominal (+11 V to
+30 V)
Input current:
• From the drive: 180 mA typical, 300 mA
maximum (+3.3 V)
• From the network: 20 mA typical, 50 mA
maximum (+24 V)
General Estimated min. lifetime 100 000 h
All materials UL/CSA-approved
Complies with EMC standard EN 61800-3:2004
Bus interface functionally isolated from the drive
Printed circuit board conformal coated
Compatible devices Any ODVA-compliant DeviceNet scanner
supporting Poll - Response commands to Group
2 only Slaves
Medium • DeviceNet cables: YR-29790 (Thick DeviceNet
Cable), YR-29832 (Thin DeviceNet Cable)
• Termination: 121 ohm, 1%, Metal Film, 1/4 W
• Maximum bus length: 1200 m
Topology Multi-drop
Transfer rate 125, 250 or 500 kBit/s
Serial communication
type
Asynchronous, Half duplex
Protocol DeviceNet

ABB FDNA-01 Specifications

General

Brand	ABB
Model	FDNA-01
Category	Control Unit
Language	English
