ABB FDNA-01 User Manual

Start-up 47
FDNA-01 configuration parameters – group B (group 2)
Note: The actual parameter group number depends on the drive
type. Group B (group 2) corresponds to:
• parameter group 55 in ACS355
• parameter group 53 in ACSM1, ACS850 and ACQ810
• parameter group 53 in ACS880 if the adapter is installed as
fieldbus adapter A or group 56 if the adapter is installed as
fieldbus adapter B.
No.
1)
Name/Value Description Default
01 DATA OUT 1
(master to drive)
In the output assembly instances that include
drive parameters, this parameter specifies
which parameter’s value is placed in location
DATA OUT 1 value received by the drive from
the DeviceNet network. Content is defined by a
decimal number in the range of 0 to 9999 as
follows:
0
ACS355:
FBA DATA OUT 1
ACSM1:
FBA DATA OUT1
ACS850/ACQ810/
ACS880:
FBA data out1
Note: The FDNA-01 configuration parameters
are 16-bit parameters. If the mapped parameter
is a 32-bit parameter, it automatically reserves
two consecutive parameters. For example,
mapping a 32-bit parameter to parameter no. 1
also reserves parameter no. 2.
0 Not used
101…9999 Parameter index with format xxyy, where xx is
the parameter group number (1…99) and yy is
the parameter number index within that group
(01…99).
02…
10
DATA OUT 2…
DATA OUT 10
See parameter DATA OUT 1.0
1)
The number of parameters in this group may vary by drive type and drive firmware.
0Not used
1…99 Virtual address area of drive control.
Not used with the FDNA-01 module.
101…
9999
Parameter area of the drive
