ABB FDNA-01 User Manual

Communication protocol 125
 Transparent 32 with one assembly
The Transparent 32 with one assembly, defined by ABB, provides
unaltered 32-bit access to the configured drive profile.
The format of the output assembly is:
The format of the input assembly is:
Instance 821
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Drive Profile 32-bit Control word (Low Byte)
1 Drive Profile 32-bit Control word
2 Drive Profile 32-bit Control word
3 Drive Profile 32-bit Control word (High Byte)
4 Drive Profile 32-bit Reference 1 word (Low Byte)
5 Drive Profile 32-bit Reference 1 word
6 Drive Profile 32-bit Reference 1 word
7 Drive Profile 32-bit Reference 1 word (High Byte)
Instance 871
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Drive Profile 32-bit Status word (Low Byte)
1 Drive Profile 32-bit Status word
2 Drive Profile 32-bit Status word
3 Drive Profile 32-bit Status word (High Byte)
4 Drive Profile 32-bit Actual 1 word (Low Byte)
5 Drive Profile 32-bit Actual 1 word
6 Drive Profile 32-bit Actual 1 word
7 Drive Profile 32-bit Actual 1 word (High Byte)
