IRB 2600 Type C-20/1.65, IRB 2600 Type C-12/1.65
xx1800001132
Oil plug, inspectionA
Location of oil plugs (suspended mounted)
The axis 1 gearbox is located between the frame and base of the robot. The oil
plug for inspection is shown in the figure.
IRB 2600-20/1.65, IRB 2600-12/1.65, IRB 2600-12/1.85, IRB 2600ID-15/1.85, IRB 2600ID-8/2.0
A
B
xx1200000883
Oil plug, inspection, with sealing washerA
Oil plugB
IRB 2600 Type C-20/1.65, IRB 2600 Type C-12/1.65
IRB 2600 Type C-20/1.65, IRB 2600 Type C-12/1.65 is not available for suspended
installation.
Continues on next page
120 Product manual - IRB 2600
3HAC035504-001 Revision: Q
© Copyright 2009-2018 ABB. All rights reserved.
3 Maintenance
3.3.1 Inspecting oil level, axis-1 gearbox
Continued
