Lifting instructions
Use this procedure to lift the robot in a safe way.
NoteAction
CAUTION
The IRB 2600/IRB 2600 ID robot weighs 280
kg.
All lifting accessories used must be sized ac-
cordingly!
1
CAUTION
Attempting to lift the robot in any other posi-
tion than that recommended may result in the
robot tipping over and causing severe damage
or injury!
2
WARNING
Personnel must not, under any circumstances,
be present under the suspended load!
3
Detailed in section:
• Risk of tipping/stability on
page 59
Move the robot to its most stable position.
For robot versions IRB 2600ID: The best pos-
ition of axis 4 is ±90°.
4
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot working
area.
5
See the figure in:
• Lifting on page 60
Attach roundsling A to the lifting lug on the
frame, and put folded in a U-shape on either
side of the upper arm.
6
See the figure in:
• Lifting on page 60
Attach roundsling B at axis 3 gearbox by run-
ning it folded in a U-shape around the gear-
box.
7
Make sure the roundslings do not rub against
any sharp edges.
8
Continues on next page
Product manual - IRB 2600 61
3HAC035504-001 Revision: Q
© Copyright 2009-2018 ABB. All rights reserved.
2 Installation and commissioning
2.3.1 Lifting robot with roundslings
Continued
