The backlight turns on and the panel is ready for further operations.
If the panel has not been used for a predefined timeout period, the backlight is
switched off. The user is logged out from the current user level 30 seconds after the
display backlight has turned off.
The display returns to the default view and all unconfirmed operations such as
parameter editing and breaker selection are cancelled.
Change the backlight timeout period in Main Menu/
Configuration/HMI/Backlight timeout.
4.1.4 Selecting local or remote use
The control position of the IED can be changed with the R/L button. In local position
primary equipment, such as circuit breakers and disconnectors, can be controlled via
the LHMI. In remote position, control operations are possible only from a higher
level, that is from a control center.
•
Press
for two seconds.
• When the L LED is lit, local control is enabled and remote control disabled.
• When the R LED is lit, remote control is enabled and local control disabled.
• When none of the LEDs are lit, both control positions are disabled.
The control position cannot be simultaneously local and remote,
but it can be disabled when neither of the positions is active.
You must be logged in and authorized to control the IED.
4.1.5 Identifying the device
The IED information includes detailed information about the device, such as revision
and serial number.
The IED information is shown on the display for a few seconds when the device starts
up. The same information is also found in the IED menu.
1. Select Main Menu/Information.
2.
Select a submenu with and .
1MRS756499 A Section 4
Using HMI locally or via web interface
RED615 31
Operation Manual
