ABB TRIO-20.0/27.6-TL-OUTD User Manual

- 14 -
000009EG
2 - Characteristics
Models and range of equipment
The specic models of three-phase inverters that this manual is about
are divided into two groups according to the maximum output power:
20kW or 27.6 kW.
For inverters of equal output power, the variant between the various
models is the layout of the wiring box
02
.
The choice of model of inverter must be made by a qualied technician who knows about
the installation conditions, the devices that will be installed outside the inverter and possible
integration with an existing system.
• 20.0kW three-phase MODELS • 27.6 kW three-phase MODELS
TRIO-20.0-TL-OUTD-400:
• Nominal output power: 20.0kW
• Number of input channels: 2
• Input connectors: screw terminal block
13
• AC+DC Disconnect switch
14
: No
• DC overvoltage surge arresters
15
: No
• AC overvoltage surge arresters
18
: No
• String protection fuses
22
No
TRIO-27.6-TL-OUTD-400:
• Nominal output power: 27.6kW
• Number of input channels: 2
• Input connectors: screw terminal block
13
• AC+DC Disconnect switch
14
: No
• DC overvoltage surge arresters
15
: No
• AC overvoltage surge arresters
18
: No
• String protection fuses
22
No
TRIO-20.0-TL-OUTD-S2-400:
• Nominal output power: 20.0kW
• Number of input channels: 2
• Input connectors: screw terminal block
13
• AC+DC Disconnect switch
14
: Yes
• DC overvoltage surge arresters
15
: No
• AC overvoltage surge arresters
18
: No
• String protection fuses
22
No
TRIO-27.6-TL-OUTD-S2-400:
• Nominal output power: 27.6kW
• Number of input channels: 2
• Input connectors: screw terminal block
13
• AC+DC Disconnect switch
14
: Yes
• DC overvoltage surge arresters
15
: No
• AC overvoltage surge arresters
18
: No
• String protection fuses
22
No
TRIO-20.0-TL-OUTD-S2F-400:
• Nominal output power: 20.0kW
• Number of input channels: 2
• Input connectors: quick t connectors (4 pairs for
each channel)
• AC+DC Disconnect switch
14
: Yes
• DC overvoltage surge arresters
15
: No
• AC overvoltage surge arresters
18
: No
• String protection fuses
22
Yes
TRIO-27.6-TL-OUTD-S2F-400:
• Nominal output power: 27.6kW
• Number of input channels: 2
• Input connectors: quick t connectors (5 pairs for
each channel)
• AC+DC Disconnect switch
14
: Yes
• DC overvoltage surge arresters
15
: No
• AC overvoltage surge arresters
18
: No
• String protection fuses
22
Yes
TRIO-20.0-TL-OUTD-S2X-400:
• Nominal output power: 20.0kW
• Number of input channels: 2
• Input connectors: quick t connectors (4 pairs for
each channel)
• AC+DC Disconnect switch
14
: Yes
• DC overvoltage surge arresters
15
: Yes
• AC overvoltage surge arresters
18
: Yes
• String protection fuses
22
Yes
TRIO-27.6-TL-OUTD-S2X-400:
• Nominal output power: 27.6kW
• Number of input channels: 2
• Input connectors: quick t connectors (5 pairs for
each channel)
• AC+DC Disconnect switch
14
: Yes
• DC overvoltage surge arresters
15
: Yes
• AC overvoltage surge arresters
18
: Yes
• String protection fuses
22
Yes
